- Heavy-Duty, All Welded Aluminum
- Adjustable Bullet Feet
- Standard for Easy Leveling
- 1500 lb. Capacity Per Shelf
- Maximum Capacity for Evenly Distributed, Static Load
- Designed for Institutional and Correctional Use
- Square Tubular Design
- Optional – Factory Installed*
- 8″ x 2″ Low Noise Gray Casters
- 600 lb. Capacity Per Caster
- Rigid Plate, Swivel Plate, Locking Swivel Plate
* Note: Casters are factory installed and may not be added at a later date.
More Information
Download »
Institutional All Welded Square Bar Shelving Specs
| Model Number | Shelf Qty. | Shelf Clearance | Size W x H x L | Shelf Laterals |
|---|---|---|---|---|
| SWB204836-2 | 2 | 34 1/2" | 20" x 48" x 36" | 4 |
| SWB204842-2 | 2 | 34 1/2" | 20" x 48" x 42" | 4 |
| SWB204848-2 | 2 | 34 1/2" | 20" x 48" x 48" | 4 |
| SWB204860-2 | 2 | 34 1/2" | 20" x 48" x 60" | 4 |
| SWB204872-2 | 2 | 34 1/2" | 20" x 48" x 72" | 4 |
| SWB244836-2 | 2 | 34 1/2" | 24" x 48" x 36" | 5 |
| SWB244842-2 | 2 | 34 1/2" | 24" x 48" x 42" | 5 |
| SWB244848-2 | 2 | 34 1/2" | 24" x 48" x 48" | 5 |
| SWB244860-2 | 2 | 34 1/2" | 24" x 48" x 60" | 5 |
| SWB244872-2 | 2 | 34 1/2" | 24" x 48" x 72" | 5 |
| SWB206036-3 | 3 | 22 1/2" | 20" x 60" x 36" | 4 |
| SWB206042-3 | 3 | 22 1/2" | 20" x 60" x 42" | 4 |
| SWB206048-3 | 3 | 22 1/2" | 20" x 60" x 48" | 4 |
| SWB206060-3 | 3 | 22 1/2" | 20" x 60" x 60" | 4 |
| SWB206072-3 | 3 | 22 1/2" | 20" x 60" x 72" | 4 |
| SWB246036-3 | 3 | 22 1/2" | 24" x 60" x 36" | 5 |
| SWB246042-3 | 3 | 22 1/2" | 24" x 60" x 42" | 5 |
| SWB246048-3 | 3 | 22 1/2" | 24" x 60" x 48" | 5 |
| SWB246060-3 | 3 | 22 1/2" | 24" x 60" x 60" | 5 |
| SWB246072-3 | 3 | 22 1/2" | 24" x 60" x 72" | 5 |
| SWB207236-4 | 4 | 18 1/2" | 20" x 72" x 36" | 4 |
| SWB207242-4 | 4 | 18 1/2" | 20" x 72" x 42" | 4 |
| SWB207248-4 | 4 | 18 1/2" | 20" x 72" x 48" | 4 |
| SWB207260-4 | 4 | 18 1/2" | 20" x 72" x 60" | 4 |
| SWB207272-4 | 4 | 18 1/2" | 20" x 72" x 72" | 4 |
| SWB247236-4 | 4 | 18 1/2" | 24" x 72" x 36" | 5 |
| SWB247242-4 | 4 | 18 1/2" | 24" x 72" x 42" | 5 |
| SWB247248-4 | 4 | 18 1/2" | 24" x 72" x 48" | 5 |
| SWB247260-4 | 4 | 18 1/2" | 24" x 72" x 60" | 5 |
| SWB247272-4 | 4 | 18 1/2" | 24" x 72" x 72" | 5 |
